晶振详细参数
Item
Standard specifications
Frequency Range F0
8 to 9.999MHz
10 to 11.999MHz
12 to 23.999MHz
24 to 54.00MHz
Mode of Vibration
Fundamental
Load Capacitance CL
10pF to Series
Frequency Tolerance △F/ F0
±10ppm, ±30ppm,±50ppm(At 25℃)
Equivalent Series Resistance ESR
120 Ωmax.
80Ω max.
50Ω max.
30Ω max.
Temperature Stability TC
±10ppm,±30ppm,±50ppm(Refer to 25℃)
Operating Temperature Range TOPR
-20~+70℃ -40~+85℃ Option
Storage Temperature Range TSTG
-55~+125℃
Shunt Capacitance C0
7pF max.
Insulator Resistance IR
500MΩ min. (At 100V)
Drive Level DL
100µW (300µW max.)
Aging Fa
±2ppm max. (At 25℃, First year)
Packing Unit
1000pcs/reel
晶振尺寸
